Technical specifications

Ampere 32 A
Poles 4 Pin
Voltage 415V
Clock position 3h
Hertz 50-60 Hz
Protection type IP67
Weight 2000 Grms

Description

Main Features of Industrial Connectors:

1) 16Amp, 32Amp, and 63Amp Connectors use soft contact technology.
2) These industrial connectors use superior insertion and retention performance.
3) These industrial connectors are available in 3-pole, 4-pole, and 5-pole.
4) The industrial connectors are available in the safety rating of IP44 and IP67.
5) These power connectors are made of ABS PA-6 material for their rough use and long life.
6) They are available in various ampere ratings like 16 amp, 32 amp, 63 amp, and 125 amp while the different current ratings available is 220V and 440V.

Additional information

Voltage(V)

415V

Current(A)

32A

Number of poles

4P

Protection Degree

IP67
